Mechanical System 3d modeling and rendering
When Portside Systems is involved in the mechanical design and implementation of a project we bring it to the next level with complete 3D modeling of the system. This allows us to find the issues before we encounter them and also have the most accurate BOM possible when it comes to the fabrication and construction phases. Since we develop a 3D model of the system, making modifications and seeing the effect both in a spacial and functional sense is easy. Having a rendering of the system is also a great tool for review with the design team and customer.
3D Modeling and Rendering of Facilities and Process Equipment
Hydraulic Vibration Controller
8D Lithium Ion Battery with Battery Cell Managment
Solar Powered Security System
Conversion of 3D Models to Scaled 2D Drawing Sets for Review and for Construction.
HVAC Thermal Storage Unit
Main Pumping Station
DC Battery Power Storage
Custom Battery Storage System
Custom Enclosures / 3D Modeling / 3D Printing
Full capabilities of designing and fabricating fixtures and components to meet your projects needs!
We use our CNC router for making custom parts for control panel, custom pipe flanges, custom polypropylene parts to be welded into assemblies, and general industrial signage for use on our projects.
We use our 3D printer to prototype parts before they are sent out to the machine shop and also for making fixtures and brackets for our control panel and mechanical assemblies.
